5 Ton Capacity Water Cooled Shell-and-Tube Heat Exchanger Condenser

Our company has formed its own unique development mode and distinctive business positioning. Our company adheres to the customer-oriented principle and always pays attention to the needs of consumers and try our best to provide best Cold Room Air Cooler, H Type Air Cooled Condenser, Semi-hermetic Condensing Unit for them. We keep our commitment to continuous innovation and we invest a portion of our annual sales into technology. In the future development, our company will be on the basis of stabilizing the sales of existing products, committed to the development of its own products, the company will develop into a large-scale, diversified, sustainable development of trade, industry, science and technology enterprises. We give full play to the potential of our brand resources and use our brand value to create the most benefits for our company.

Shell: A cylindrical tank made of carbon steel or stainless steel, housing the heat exchange tubes.

Tube Bundle: Made of high-quality copper or copper-nickel alloy, the tubes carry refrigerant while cooling water flows over them.

Tube Sheets & Baffles: Support and direct water flow, maximizing turbulence and heat transfer.

Removable Water Heads: For cleaning and maintenance access to the tubes.

Working Principle
High-pressure refrigerant gas enters the tube side.

Cooling water flows across the outer surface of the tubes inside the shell.

As heat is exchanged, the refrigerant condenses into a liquid.

The condensed refrigerant exits to the receiver or expansion valve, while the heated water is discharged or recirculated.

Main Features
✅ Excellent Heat Transfer
Copper tubes with optional internal finning or rifling for enhanced thermal efficiency.

✅ Robust Construction
Thick shell wall and tube sheets ensure high working pressure resistance (typically 2.5–3.0 MPa).

✅ Wide Refrigerant Compatibility
Supports R22, R404A, R134a, R507A, R410A, etc.

✅ Anti-Corrosion Options
Available with epoxy coating, rubber lining, or Cu-Ni alloy tubes for coastal or chemical environments.

✅ Easy Maintenance
Both ends are fitted with removable water chambers, allowing for mechanical cleaning and inspection of the tube bundle.

Application

Commercial & industrial chillers
Cold storage condensing units
HVAC systems in hotels, malls, hospitals
Food, dairy & seafood processing
Chemical and pharmaceutical cooling
Ice machines and low-temp systems

Note:e1 stands for pressure gauge connection, which is 1/4", e stands for fusible plug connection, which is 3/8"

C-series water cooled condenser

Note: connection of pressure gauge is 1/4", connection of fusible plug is 3/8"

Dual system water cooled condenser

Note: connection of pressure gauge is 1/4", connection of fusible plug is 3/8"
